AIM Refrigeration snow falling machines are designed for indoor snow scenes, snow rooms, commercial entertainment venues, event snow effects and snow park projects where stable snow output, refrigeration configuration and installation layout need to be reviewed together.
Snow falling machine for commercial snow effects
Snow falling equipment is selected by the required snow effect, coverage width, daily operating time, indoor temperature, water quality and installation position. For a small retail display, a compact FAS model may be enough. For a snow room or attraction venue, a larger F series system with air or water cooling can provide stronger output and better project stability.
The models below are used for preliminary selection. Final configuration should be checked against the project layout, ceiling height, refrigeration room location, water pressure, drainage, power supply and maintenance access.
Snow falling machine model range
Compare six snow falling machine models from compact event systems to larger commercial snow venue configurations.
| Specification | Unit | FAS-1300G | FAS-2000G | FAS-5500G | F26 | F26L | F56 |
|---|---|---|---|---|---|---|---|
| Input power | Voltage / Phase / Hz | 220V/380V/440V 3P 50Hz-60Hz | 220V/380V/440V 3P 50Hz-60Hz | 220V/380V/440V 3P 50Hz-60Hz | 220V/380V/440V 3P 50Hz-60Hz | 220V/380V/440V 3P 50Hz-60Hz | 220V/380V/440V 3P 50Hz-60Hz |
| Refrigerant | / | R507A / R454C | R507A / R454C | R507A / R454C | R507A / R454C | R507A / R454C | R507A / R454C |
| Snow capacity | kg/day | 600 | 1,000 | 2,000 | 4,000 | 4,000 | 6,000 |
| Condenser fan power | kW | 0.35 | 0.49 | 0.96 | 1.5 | 1.5 | 2.2 |
| Cooling method | / | Air cooling | Air cooling | Air cooling | Air / water cooling | Air / water cooling | Air / water cooling |
| Compressor manufacturer | / | Copeland | Copeland | Copeland | Copeland | Copeland | Bock |
| Compressor operating power | kW | 3 | 5 | 8 | 13.5 | 13.5 | 21 |
| Compressor horsepower | HP | 4 | 5 | 8 | 15 | 15 | 28 |
| Snow falling system size | L x W x H | 600 x 600 x 425 mm | 1088 x 8350 x 550 mm | 1680 x 800 x 925 mm | 2017 x 1040 x 810 mm | 3507 x 832 x 505 mm | 2040 x 1260 x 840 mm |
| Refrigeration system size | L x W x H | 680 x 820 x 630 mm | 1200 x 500 x 950 mm | 1680 x 1202 x 930 mm | 1850 x 1630 x 900 mm | 1850 x 1630 x 900 mm | 2370 x 900 x 1970 mm |
| Snow falling system weight | kg | 68 | 210 | 310 | 550 | 600 | 900 |
| Refrigeration system weight | kg | 88 | 28 | 540 | 800 | 800 | 350 |
| Electrical cabinet weight | kg | 18 | 60 | 110 | 110 | 110 | 110 |
FAS-1300G
600 kg/day compact snow falling system
- Best-fit application
- Small indoor snow scenes and retail displays
- Input power (Voltage / Phase / Hz)
- 220V/380V/440V 3P 50Hz-60Hz
- Refrigerant
- R507A / R454C
- Snow capacity (kg/day)
- 600
- Condenser fan power (kW)
- 0.35
- Cooling method
- Air cooling
- Compressor manufacturer
- Copeland
- Compressor operating power (kW)
- 3
- Compressor horsepower (HP)
- 4
- Snow falling system size (L x W x H)
- 600 x 600 x 425 mm
- Refrigeration system size (L x W x H)
- 680 x 820 x 630 mm
- Snow falling system weight (kg)
- 68
- Refrigeration system weight (kg)
- 88
- Electrical cabinet weight (kg)
- 18
FAS-2000G
1,000 kg/day event and venue model
- Best-fit application
- Commercial snow effects and medium indoor projects
- Input power (Voltage / Phase / Hz)
- 220V/380V/440V 3P 50Hz-60Hz
- Refrigerant
- R507A / R454C
- Snow capacity (kg/day)
- 1,000
- Condenser fan power (kW)
- 0.49
- Cooling method
- Air cooling
- Compressor manufacturer
- Copeland
- Compressor operating power (kW)
- 5
- Compressor horsepower (HP)
- 5
- Snow falling system size (L x W x H)
- 1088 x 8350 x 550 mm
- Refrigeration system size (L x W x H)
- 1200 x 500 x 950 mm
- Snow falling system weight (kg)
- 210
- Refrigeration system weight (kg)
- 28
- Electrical cabinet weight (kg)
- 60
FAS-5500G
2,000 kg/day higher-capacity snow effect system
- Best-fit application
- Larger snow rooms and attraction areas
- Input power (Voltage / Phase / Hz)
- 220V/380V/440V 3P 50Hz-60Hz
- Refrigerant
- R507A / R454C
- Snow capacity (kg/day)
- 2,000
- Condenser fan power (kW)
- 0.96
- Cooling method
- Air cooling
- Compressor manufacturer
- Copeland
- Compressor operating power (kW)
- 8
- Compressor horsepower (HP)
- 8
- Snow falling system size (L x W x H)
- 1680 x 800 x 925 mm
- Refrigeration system size (L x W x H)
- 1680 x 1202 x 930 mm
- Snow falling system weight (kg)
- 310
- Refrigeration system weight (kg)
- 540
- Electrical cabinet weight (kg)
- 110
F26
4,000 kg/day system with air or water cooling
- Best-fit application
- Professional snow venues needing stronger output
- Input power (Voltage / Phase / Hz)
- 220V/380V/440V 3P 50Hz-60Hz
- Refrigerant
- R507A / R454C
- Snow capacity (kg/day)
- 4,000
- Condenser fan power (kW)
- 1.5
- Cooling method
- Air / water cooling
- Compressor manufacturer
- Copeland
- Compressor operating power (kW)
- 13.5
- Compressor horsepower (HP)
- 15
- Snow falling system size (L x W x H)
- 2017 x 1040 x 810 mm
- Refrigeration system size (L x W x H)
- 1850 x 1630 x 900 mm
- Snow falling system weight (kg)
- 550
- Refrigeration system weight (kg)
- 800
- Electrical cabinet weight (kg)
- 110
F26L
4,000 kg/day long snow falling system layout
- Best-fit application
- Longer coverage width and engineered installation
- Input power (Voltage / Phase / Hz)
- 220V/380V/440V 3P 50Hz-60Hz
- Refrigerant
- R507A / R454C
- Snow capacity (kg/day)
- 4,000
- Condenser fan power (kW)
- 1.5
- Cooling method
- Air / water cooling
- Compressor manufacturer
- Copeland
- Compressor operating power (kW)
- 13.5
- Compressor horsepower (HP)
- 15
- Snow falling system size (L x W x H)
- 3507 x 832 x 505 mm
- Refrigeration system size (L x W x H)
- 1850 x 1630 x 900 mm
- Snow falling system weight (kg)
- 600
- Refrigeration system weight (kg)
- 800
- Electrical cabinet weight (kg)
- 110
F56
6,000 kg/day large commercial snow model
- Best-fit application
- Snow parks, indoor attractions and high-demand venues
- Input power (Voltage / Phase / Hz)
- 220V/380V/440V 3P 50Hz-60Hz
- Refrigerant
- R507A / R454C
- Snow capacity (kg/day)
- 6,000
- Condenser fan power (kW)
- 2.2
- Cooling method
- Air / water cooling
- Compressor manufacturer
- Bock
- Compressor operating power (kW)
- 21
- Compressor horsepower (HP)
- 28
- Snow falling system size (L x W x H)
- 2040 x 1260 x 840 mm
- Refrigeration system size (L x W x H)
- 2370 x 900 x 1970 mm
- Snow falling system weight (kg)
- 900
- Refrigeration system weight (kg)
- 350
- Electrical cabinet weight (kg)
- 110
Specification data is based on AIM snow machine model information and is intended for preliminary selection. Final project quotation should confirm snow coverage area, installation condition, water quality, voltage and operating schedule.
Selection details to confirm
Falling snow volume and coverage
Confirm whether the project needs light atmospheric snow, stronger visible falling snow or continuous snow accumulation.
Ceiling, machine room and route
Installation height, snow outlet position, refrigeration unit location and service access affect model selection.
Power, water and drainage
Voltage, frequency, water quality, water pressure and drainage planning should be checked before quotation.
Daily schedule and venue use
Event duration, visitor flow and daily operating hours determine the required output and cooling configuration.
Designed as part of the snow venue system
A snow falling machine is often connected with refrigeration equipment, water treatment, control cabinet, snow outlet design and venue operation planning. AIM can help review the complete system instead of quoting only one machine model.
Related pages: Snow Machine, Four-Season Snow Machine, Snow Park Equipment.
Need a snow falling machine proposal?
Send snow area, venue type, ceiling height, operating hours, voltage and required snow effect. AIM Refrigeration will help match the suitable model and system layout.
Technical questions buyers ask before choosing Snow Falling Machine.
These points help overseas buyers compare capacity, condenser type, project data and equipment scope before requesting a quotation from AIM Refrigeration.
What data is needed for an AIM equipment quotation?
Share product type, required capacity, installation country, voltage, ambient temperature, inlet water or product temperature, operating schedule and application details.
Can AIM configure equipment for overseas projects?
Yes. AIM reviews climate, power supply, layout, capacity and workflow before proposing a suitable refrigeration or ice-making configuration.
Does AIM provide technical documents before purchase?
AIM can prepare quotation assumptions, model information and technical documentation according to the confirmed project scope.
