Containerized All Weather Snow Machine systems for indoor snow parks, snow rooms, commercial attractions and warm-climate year-round snow projects.
Four-season snow machine for year-round snow projects
AIM Refrigeration builds All Weather Snow Machine systems for projects where snow quality, operating stability and installation layout must be planned together. The equipment is designed to support snow production in warm weather and changing venue conditions, rather than relying only on natural winter temperatures. Unlike a simple snow effect device, this equipment is normally selected as part of a complete snow project, with refrigeration, water treatment, snow delivery, air movement and site conditions reviewed before production.
The system is suitable for indoor snow parks, family entertainment centers, themed retail spaces, training rooms, event venues and four-season snow attractions in warm regions. For each project, the model should be matched to the venue area, required snow depth, operating schedule, air temperature, water temperature and snow conveying distance.
Four-season snow machine model range
The model range below is used for preliminary All Weather Snow Machine project selection. EastSnow, WestSnow, SouthSnow, NorthSnow and MiddleSnow cover different production capacities and container configurations, from compact indoor snow scenes to larger snow park applications.
| Specification | EastSnow | WestSnow | SouthSnow | NorthSnow | MiddleSnow |
|---|---|---|---|---|---|
| Container size | 20F | 40HF | 40HF | 40HF | 40HF |
| Container quantity | 1 | 1 | 2 | 2 | 2 |
| Air temperature range | -25°C to +36°C | -25°C to +36°C | -25°C to +36°C | -25°C to +36°C | -25°C to +36°C |
| Water temperature range | 2°C to 22°C | 2°C to 22°C | 2°C to 22°C | 2°C to 22°C | 2°C to 22°C |
| Snow production | 66 m³ | 30 t/d | 100 m³ | 45 t/d | 180 m³ | 80 t/d | 270 m³ | 120 t/d | 352 m³ | 160 t/d |
| Transport distance | 20-50 m | 50-70 m | 50-80 m | 50-100 m | 50-100 m |
| Design air temperature | 20°C | 20°C | 20°C | 20°C | 20°C |
| Design water temperature | 10°C | 10°C | 10°C | 10°C | 10°C |
| Refrigerant | R507 / R449A | R507 / R449A | R507 / R449A | R507 / R449A / R717 | R717 |
| Power supply | 400V-3Ph/N/PE-50Hz | 400V-3Ph/N/PE-50Hz | 400V-3Ph/N/PE-50Hz | 400V-3Ph/N/PE-50Hz | 400V-3Ph/N/PE-50Hz |
| Nominal power | 96 kW | 140 kW | 254 kW | 360 kW (R449A) | 287 kW |
| Relative energy consumption | 35 kWh/m³ | 35 kWh/m³ | 35 kWh/m³ | 35 kWh/m³ | 20 kWh/m³ |
| Water connection | 3/4" – PN16 | 3/4" – PN16 | 1-1/4" – PN16 | 1-1/4" – PN16 | 1-1/4" – PN16 |
| Water pressure | 2-5 bar | 2-5 bar | 2-5 bar | 2-5 bar | 2-5 bar |
| Blower connection | DN160 | DN160 | DN160 | DN160 x 2 | DN160 x 2 |
| Weight | 10,500 kg | 17,500 kg | 22,000 kg | 30,000 kg | 33,600 kg |
| Dimensions | 6 m / 2.4 m / 2.4 m | 12 m / 2.4 m / 2.9 m | 12 m / 2.4 m / 2.9 m | 12 m / 2.4 m / 2.9 m | 12 m / 2.4 m / 2.9 m |
EastSnow
66 m³ | 30 t/d snow production
- Container size
- 20F
- Container quantity
- 1
- Air temperature range
- -25°C to +36°C
- Water temperature range
- 2°C to 22°C
- Transport distance
- 20-50 m
- Design air temperature
- 20°C
- Design water temperature
- 10°C
- Refrigerant
- R507 / R449A
- Power supply
- 400V-3Ph/N/PE-50Hz
- Nominal power
- 96 kW
- Relative energy consumption
- 35 kWh/m³
- Water connection
- 3/4" – PN16
- Water pressure
- 2-5 bar
- Blower connection
- DN160
- Weight
- 10,500 kg
- Dimensions
- 6 m / 2.4 m / 2.4 m
WestSnow
100 m³ | 45 t/d snow production
- Container size
- 40HF
- Container quantity
- 1
- Air temperature range
- -25°C to +36°C
- Water temperature range
- 2°C to 22°C
- Transport distance
- 50-70 m
- Design air temperature
- 20°C
- Design water temperature
- 10°C
- Refrigerant
- R507 / R449A
- Power supply
- 400V-3Ph/N/PE-50Hz
- Nominal power
- 140 kW
- Relative energy consumption
- 35 kWh/m³
- Water connection
- 3/4" – PN16
- Water pressure
- 2-5 bar
- Blower connection
- DN160
- Weight
- 17,500 kg
- Dimensions
- 12 m / 2.4 m / 2.9 m
SouthSnow
180 m³ | 80 t/d snow production
- Container size
- 40HF
- Container quantity
- 2
- Air temperature range
- -25°C to +36°C
- Water temperature range
- 2°C to 22°C
- Transport distance
- 50-80 m
- Design air temperature
- 20°C
- Design water temperature
- 10°C
- Refrigerant
- R507 / R449A
- Power supply
- 400V-3Ph/N/PE-50Hz
- Nominal power
- 254 kW
- Relative energy consumption
- 35 kWh/m³
- Water connection
- 1-1/4" – PN16
- Water pressure
- 2-5 bar
- Blower connection
- DN160
- Weight
- 22,000 kg
- Dimensions
- 12 m / 2.4 m / 2.9 m
NorthSnow
270 m³ | 120 t/d snow production
- Container size
- 40HF
- Container quantity
- 2
- Air temperature range
- -25°C to +36°C
- Water temperature range
- 2°C to 22°C
- Transport distance
- 50-100 m
- Design air temperature
- 20°C
- Design water temperature
- 10°C
- Refrigerant
- R507 / R449A / R717
- Power supply
- 400V-3Ph/N/PE-50Hz
- Nominal power
- 360 kW (R449A)
- Relative energy consumption
- 35 kWh/m³
- Water connection
- 1-1/4" – PN16
- Water pressure
- 2-5 bar
- Blower connection
- DN160 x 2
- Weight
- 30,000 kg
- Dimensions
- 12 m / 2.4 m / 2.9 m
MiddleSnow
352 m³ | 160 t/d snow production
- Container size
- 40HF
- Container quantity
- 2
- Air temperature range
- -25°C to +36°C
- Water temperature range
- 2°C to 22°C
- Transport distance
- 50-100 m
- Design air temperature
- 20°C
- Design water temperature
- 10°C
- Refrigerant
- R717
- Power supply
- 400V-3Ph/N/PE-50Hz
- Nominal power
- 287 kW
- Relative energy consumption
- 20 kWh/m³
- Water connection
- 1-1/4" – PN16
- Water pressure
- 2-5 bar
- Blower connection
- DN160 x 2
- Weight
- 33,600 kg
- Dimensions
- 12 m / 2.4 m / 2.9 m
Model data is for preliminary selection. Final configuration should be reviewed according to venue size, target snow effect, local ambient condition, water quality, voltage, installation layout and daily operating hours.
How AIM selects the right system
For snow attraction projects, capacity alone is not enough. AIM Refrigeration reviews the expected visitor flow, required snow coverage, indoor humidity, air conditioning load, snow delivery route and maintenance access before recommending a model. For larger snow parks, the snow machine can be coordinated with cold storage, snow conveying and venue refrigeration equipment to improve operating reliability.
Related project pages: Snow machine, Snow park and Ice rink.
Project inquiry
To prepare a practical selection, please share the snow area, indoor or outdoor condition, local summer temperature, preferred operating hours, power supply and required snow effect. AIM can then recommend a suitable model and system layout for quotation.
Technical questions buyers ask before choosing All Weather Snow Machine.
These points help overseas buyers compare capacity, condenser type, project data and equipment scope before requesting a quotation from AIM Refrigeration.
What data is needed for an AIM equipment quotation?
Share product type, required capacity, installation country, voltage, ambient temperature, inlet water or product temperature, operating schedule and application details.
Can AIM configure equipment for overseas projects?
Yes. AIM reviews climate, power supply, layout, capacity and workflow before proposing a suitable refrigeration or ice-making configuration.
Does AIM provide technical documents before purchase?
AIM can prepare quotation assumptions, model information and technical documentation according to the confirmed project scope.
